MAX9108EUD データシート

Name: MAX9108EUD
Brand: MAXIM
SKU: 230333274-0000-0000-0000

MAX9108EUD - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX9108EUD の詳細情報

型番	MAX9108EUD
メーカー	MAXIM
データシート
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	0.35 uA
Average Bias Current-Max (IIB) (uA)	0.35
Bias Current-Max (IIB) @25C	0.35 uA
Bias Current-Max (IIB) @25C (uA)	0.35
DLA Qualification	Not Qualified
Input Offset Voltage-Max	4000 uV
Input Offset Voltage-Max (uV)	4000
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G14
JESD-609 Code	e0
Length	5 mm
Length (mm)	5
Moisture Sensitivity Level	1
Number of Functions	4
Number of Terminals	14
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP14,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Power Supplies (V)	5
Qualification Status	Not Qualified
Response Time-Nom	25 ns
Seated Height-Max	1.1 mm
Seated Height-Max (mm)	1.1
Sub Category	Comparator
Supply Current-Max	0.7 mA
Supply Current-Max (mA)	0.7
Supply Voltage Limit-Max	6 V
Supply Voltage Limit-Max (V)	6
Supply Voltage-Nom (V)	5
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Pitch (mm)	0.65
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	4.4 mm
Width (mm)	4.4
