MAX694CPA データシート

Name: MAX694CPA
Brand: MAXIM
SKU: 230331910-0000-0000-0000

MAX694CPA - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX694CPA の詳細情報

型番	MAX694CPA
メーカー	MAXIM
データシート
Additional Feature	RESET THRESHOLD VOLTAGE IS 4.65V
Adjustable Threshold	NO
Analog IC - Other Type	POWER SUPPLY MANAGEMENT CIRCUIT
DLA Qualification	Not Qualified
J-STD-609 Code	e3
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e0
Length	9.375 mm
Length (mm)	9.375
Moisture Sensitivity Level	1
Number of Channels	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Power Supplies (V)	5
Qualification Status	Not Qualified
Seated Height-Max	4.572 mm
Seated Height-Max (mm)	4.572
Sub Category	Power Management Circuits
Supply Current-Max (Isup)	10 mA
Supply Current-Max (mA)	10
Supply Voltage-Max (V)	5.5
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (V)	4.75
Supply Voltage-Min (Vsup)	4.75 V
Supply Voltage-Nom (V)	5
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Pitch (mm)	2.54
Terminal Position	DUAL
Threshold Voltage-Nom	+4.65V V
Threshold Voltage-Nom (V)	+4.65V
Time@Peak Reflow Temperature-Max (s)	30
Width	7.62 mm
Width (mm)	7.62
