MAX6035AAUR50T データシート

Name: MAX6035AAUR50T
Brand: MAXIM
SKU: 230486749-0000-0000-0000

MAX6035AAUR50T - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX6035AAUR50T の詳細情報

型番	MAX6035AAUR50T
メーカー	MAXIM
データシート
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 Code	R-PDSO-G3
JESD-609 Code	e0
Length	2.92 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Voltage-Max	5.01 V
Output Voltage-Min	4.99 V
Output Voltage-Nom	5 V
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TO-236
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	245
Qualification Status	Not Qualified
Seated Height-Max	1.12 mm
Sub Category	Voltage References
Supply Voltage-Max (Vsup)	33 V
Supply Voltage-Min (Vsup)	6.9 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	YES
Technology	BICMOS
Temp Coef of Voltage-Max	30 ppm/Cel
Temperature Grade	AUTOMOTIVE
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	0.2 %
Width	1.3 mm
