MAX5812PEUT+T データシート

Name: MAX5812PEUT+T
Brand: MAXIM
SKU: 230501815-0000-0000-0000

MAX5812PEUT+T - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX5812PEUT+T の詳細情報

型番	MAX5812PEUT+T
メーカー	MAXIM
データシート
Analog Output Voltage-Max	5.5 V
Analog Output Voltage-Min	0 V
Converter Type	D/A CONVERTER
Input Bit Code	BINARY
Input Format	SERIAL
JESD-30 Code	R-PDSO-G6
JESD-609 Code	e3
Length	2.9 mm
Linearity Error-Max (EL)	0.3906 %
Moisture Sensitivity Level	1
Number of Bits	12
Number of Functions	1
Number of Terminals	6
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.45 mm
Settling Time-Nom (tstl)	4 us
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	BICMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	1.625 mm
