MAX550AEUA データシート

Name: MAX550AEUA
Brand: MAXIM
SKU: 230039429-0000-0000-0000

MAX550AEUA - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX550AEUA の詳細情報

型番	MAX550AEUA
メーカー	MAXIM
データシート
Analog Output Voltage-Max	5.5 V
Analog Output Voltage-Max (V)	5.5
Analog Output Voltage-Min	0 V
Analog Output Voltage-Min (V)	0
Converter Type	D/A CONVERTER
DLA Qualification	Not Qualified
Input Bit Code	BINARY
Input Format	SERIAL
J-STD-609 Code	e3
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e0
Length	3 mm
Length (mm)	3
Linearity Error-Max (EL)	0.39 %
Moisture Sensitivity Level	1
Number of Bits	8
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	245
Power Supplies	3/5 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Seated Height-Max (mm)	1.1
Settling Time-Nom (tstl)	4 us
Settling Time-Nom (tstl) (us)	4
Sub Category	Other Converters
Supply Current-Max	0.01 mA
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Pitch (mm)	0.65
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm
Width (mm)	3
