MAX5048BAUTT の詳細情報

  • 仕様・詳細
  • メーカー情報
型番MAX5048BAUTT
メーカーMAXIM
データシートProduct_list_pdf
High Side Driver YES
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
JESD-30 Code R-PDSO-G6
JESD-609 Code e0
Length 2.9 mm
Moisture Sensitivity Level 1
Number of Functions 1
Number of Terminals 6
Operating Temperature-Max 125 Cel
Operating Temperature-Min -40 Cel
Output Peak Current Limit-Nom 7.6 A
Package Body Material PLASTIC/EPOXY
Package Code LSSOP
Package Equivalence Code TSOP6,.11,37
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel) 245
Power Supplies 12 V
Qualification Status Not Qualified
Seated Height-Max 1.45 mm
Sub Category MOSFET Drivers
Supply Voltage-Max 12.6 V
Supply Voltage-Min 4 V
Supply Voltage-Nom 12 V
Surface Mount YES
Technology BICMOS
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 0.95 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Turn-off Time 0.027 us
Turn-on Time 0.027 us
Width 1.625 mm
