MAX4626EUKT データシート

Name: MAX4626EUKT
Brand: MAXIM
SKU: 230338649-0000-0000-0000

MAX4626EUKT - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX4626EUKT の詳細情報

型番	MAX4626EUKT
メーカー	MAXIM
データシート
Analog IC - Other Type	SPST
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e0
Length	2.9 mm
Moisture Sensitivity Level	1
Normal Position	NO V
Number of Channels	1
Number of Functions	1
Number of Terminals	5
Off-state Isolation-Nom	51 dB
On-state Resistance Match-Nom	0.1 ohm
On-state Resistance-Max (Ron)	0.8 ohm
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Equivalence Code	TSOP5/6,.11,37
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	245
Power Supplies	3/5 V
Qualification Status	Not Qualified
Seated Height-Max	1.45 mm
Sub Category	Multiplexer or Switches
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	1.8 V
Supply Voltage-Nom (Vsup)	3 V
Surface Mount	YES
Switch-off Time-Max	50 ns
Switch-on Time-Max	90 ns
Switching	BREAK-BEFORE-MAKE V
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Width	1.625 mm
