MAX4204EUA+ データシート

Name: MAX4204EUA+
Brand: MAXIM
SKU: 230413005-0000-0000-0000

MAX4204EUA+ - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX4204EUA+ の詳細情報

型番	MAX4204EUA+
メーカー	MAXIM
データシート
Amplifier Type	BUFFER
Average Bias Current-Max (IIB)	10 uA
Average Bias Current-Max (IIB) (uA)	10
Bandwidth (3dB)-Nom	720 MHz
Bandwidth (3dB)-Nom (MHz)	720
Bias Current-Max (IIB) @25C	10 uA
Bias Current-Max (IIB) @25C (uA)	10
DLA Qualification	Not Qualified
Input Offset Voltage-Max	15000 uV
Input Offset Voltage-Max (uV)	15000
J-STD-609 Code	e3
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e3
Length	3 mm
Length (mm)	3
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-6 V
Neg Supply Voltage Limit-Max (V)	-6
Neg Supply Voltage-Nom (Vsup)	-5 V
Negative Supply Voltage-Nom (V)	-5
Number of Functions	2
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	+-5 V
Power Supplies (V)	+-5
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Seated Height-Max (mm)	1.1
Slew Rate-Nom	4200 V/us
Slew Rate-Nom (V/us)	4200
Sub Category	Buffer Amplifiers
Supply Current-Max	4 mA
Supply Current-Max (mA)	4
Supply Voltage Limit-Max	6 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
