MAX240CMH+D
1
-
- 個
２営業日以内に回答いたします
MAX240CMH+D の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | MAX240CMH+D |
|---|---|
| メーカー | MAXIM |
| DLA Qualification | Not Qualified |
| Differential Output | NO |
| Driver Number of Bits | 5 |
| Input Characteristics | SCHMITT TRIGGER |
| Interface IC Type | LINE TRANSCEIVER |
| Interface Standard | EIA-232-E; TIA-232-E; V.28; V.24 |
| J-STD-609 Code | e3 |
| JESD-30 Code | S-PQFP-G44 |
| Length (mm) | 10 |
| Moisture Sensitivity Level | 3 |
| Number of Functions | 5 |
| Number of Terminals | 44 |
| Operating Temperature-Max (Cel) | 70 |
| Operating Temperature-Min (Cel) | 0 |
| Out Swing-Min (V) | 10 |
| Output Low Current-Max (mA) | 1.6 |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | QFP |
| Package Equivalence Code | QFP44,.5SQ,32 |
| Package Shape | SQUARE |
| Package Style | FLATPACK Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies (V) | 5 |
| Receive Delay-Max (ns) | 10000 |
| Receiver Number of Bits | 5 |
| Seated Height-Max (mm) | 2.45 |
| Sub Category | Line Driver or Receivers |
| Supply Current-Max (mA) | 15 |
| Supply Voltage-Max (V) | 5.5 |
| Supply Voltage-Min (V) | 4.5 |
| Supply Voltage-Nom (V) | 5 |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Pitch (mm) | 0.8 |
| Terminal Position | QUAD |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Transmit Delay-Max (ns) | 10000 |
| Width (mm) | 10 |
| 会社名称 | Maxim Integrated Products, Inc. |
|---|---|
| 設立 | 1983 |
| 所在地 | 160 Rio Robles San Jose, CA 95134 USA |
| URL | http://www.maxim-ic.com/ |
