MAX172BCNG データシート

Name: MAX172BCNG
Brand: MAXIM
SKU: 230006209-0000-0000-0000

MAX172BCNG - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX172BCNG の詳細情報

型番	MAX172BCNG
メーカー	MAXIM
データシート
Analog Input Voltage-Max	5 V
Analog Input Voltage-Max (V)	5
Analog Input Voltage-Min	0 V
Analog Input Voltage-Min (V)	0
Conversion Time-Max	10.4 us
Conversion Time-Max (us)	10.4
Converter Type	ADC, SUCCESSIVE APPROXIMATION
DLA Qualification	Not Qualified
J-STD-609 Code	e3
JESD-30 Code	R-PDIP-T24
JESD-609 Code	e0
Length	30.545 mm
Length (mm)	30.545
Linearity Error-Max (EL)	0.024 %
Linearity Error-Max (EL) (%)	0.024
Moisture Sensitivity Level	1
Number of Analog In Channels	1
Number of Bits	12
Number of Functions	1
Number of Terminals	24
Operating Temperature-Max	70 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Output Bit Code	BINARY
Output Format	PARALLEL, WORD
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP24,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	240
Power Supplies	5,-12/-15 V
Power Supplies (V)	5,-12/-15
Qualification Status	Not Qualified
Seated Height-Max	3.937 mm
Seated Height-Max (mm)	3.937
Sub Category	Analog to Digital Converters
Supply Current-Max	12 mA
Supply Current-Max (mA)	12
Supply Voltage-Nom	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	7.62 mm
