MAX1113CPE データシート

Name: MAX1113CPE
Brand: MAXIM
SKU: 230010320-0000-0000-0000

MAX1113CPE - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

MAX1113CPE の詳細情報

型番	MAX1113CPE
メーカー	MAXIM
データシート
Analog Input Voltage-Max	4.096 V
Analog Input Voltage-Min	0 V
Conversion Time-Max	55 us
Converter Type	ADC, SUCCESSIVE APPROXIMATION
JESD-30 Code	R-PDIP-T16
JESD-609 Code	e0
Length	19.175 mm
Linearity Error-Max (EL)	0.1953 %
Moisture Sensitivity Level	1
Number of Analog In Channels	8
Number of Bits	8
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Output Bit Code	BINARY
Output Format	SERIAL
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Sample Rate	0.05 MHz
Sample-and-Hold/Track-and-Hold	TRACK
Seated Height-Max	4.572 mm
Sub Category	Analog to Digital Converters
Supply Voltage-Nom	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	7.62 mm
