DS3231SN

Name: DS3231SN
Brand: MAXIM
SKU: 140086237-0000-0000-0000

DS3231SN - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

DS3231SN の詳細情報

型番	DS3231SN
メーカー	MAXIM
Clock Frequency-Max	0.032 MHz
External Data Bus Width	0
Information Access Method	I2C
Interrupt Capability	Y
JESD-30 Code	R-PDSO-G16
JESD-609 Code	e0
Length	10.285 mm
Moisture Sensitivity Level	1
Number of Terminals	16
Number of Timers	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP16,.4
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3 V
Qualification Status	Not Qualified
Seated Height-Max	2.65 mm
Sub Category	Timer or RTC
Supply Voltage-Max	5.5 V
Supply Voltage-Min	2.3 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time-Min	SECONDS
Time@Peak Reflow Temperature-Max (s)	20
Volatile	NO
Width	7.495 mm
uPs/uCs/Peripheral ICs Type	TIMER, REAL TIME CLOCK
