DS1245Y-120

Name: DS1245Y-120
Brand: MAXIM
SKU: 140197499-0000-0000-0000

DS1245Y-120 - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

DS1245Y-120 の詳細情報

型番	DS1245Y-120
メーカー	MAXIM
Access Time-Max (ns)	120
DLA Qualification	Not Qualified
J-STD-609 Code	e0
JESD-30 Code	R-PDIP-T32
Memory Density (bits)	1048576
Memory IC Type	NON-VOLATILE SRAM MODULE
Memory Organization	128KX8
Memory Width	8
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	32
Number of Words (words)	131072
Number of Words Code	128K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max (Cel)	70
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP32,.6
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Parallel/Serial	PARALLEL
Power Supplies (V)	5
Standby Current-Max (A)	0.0006
Sub Category	SRAMs
Supply Current-Max (mA)	85
Supply Voltage-Max (V)	5.5
Supply Voltage-Min (V)	4.5
Supply Voltage-Nom (V)	5
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch (mm)	2.54
Terminal Position	DUAL
