DG201ACJ データシート

Name: DG201ACJ
Brand: MAXIM
SKU: 140001518-0000-0000-0000

DG201ACJ - MAXIM の商品詳細ページです。

２営業日以内に回答いたします

DG201ACJ の詳細情報

型番	DG201ACJ
メーカー	MAXIM
データシート
Analog IC - Other Type	SPST
DLA Qualification	Not Qualified
J-STD-609 Code	e3
JESD-30 Code	R-PDIP-T16
JESD-609 Code	e0
Length	19.17 mm
Length (mm)	19.175
Moisture Sensitivity Level	1
Neg Supply Voltage-Max (Vsup)	-18 V
Neg Supply Voltage-Min (Vsup)	-4.5 V
Neg Supply Voltage-Nom (Vsup)	-15 V
Negative Supply Voltage-Max (V)	-18
Negative Supply Voltage-Min (V)	-4.5
Negative Supply Voltage-Nom (V)	-15
Normal Position	NC V
Number of Channels	1
Number of Functions	4
Number of Terminals	16
Off-state Isolation-Nom	70 dB
Off-state Isolation-Nom (dB)	70
On-state Resistance-Max (Ron)	175 ohm
On-state Resistance-Max (ohm)	200
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Output	SEPARATE OUTPUT V
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	240
Power Supplies	+-15 V
Qualification Status	Not Qualified
Seated Height-Max	4.572 mm
Sub Category	Multiplexer or Switches
Supply Voltage-Max (Vsup)	18 V
Supply Voltage-Min (Vsup)	4.5 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	NO
Switch-off Time-Max	450 ns
Switch-on Time-Max	600 ns
Switching	BREAK-BEFORE-MAKE V
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	7.62 mm
