DG200ABA Maxim

DG200ABA
DG200ABA
DG200ABA

DG200ABA - MAXIM の商品詳細ページです。

1

41時間17分後 以内に見積もり依頼を頂ければ、
04月23日(火) 9:00 までに見積もり回答いたします。

  • 個
この商品のお問い合わせ

DG200ABA の詳細情報

  • 仕様・詳細
  • メーカー情報
型番DG200ABA
メーカーMAXIM
Analog IC - Other Type SPST
JESD-30 Code O-MBCY-W10
JESD-609 Code e0
Moisture Sensitivity Level 1
Neg Supply Voltage-Nom (Vsup) -15 V
Normal Position NC V
Number of Channels 1
Number of Functions 2
Number of Terminals 10
Off-state Isolation-Nom 75 dB
On-state Resistance Match-Nom 80 ohm
On-state Resistance-Max (Ron) 80 ohm
Operating Temperature-Max 85 Cel
Operating Temperature-Min -25 Cel
Output SEPARATE OUTPUT V
Package Body Material METAL
Package Code TO-100
Package Equivalence Code CAN10,.23
Package Shape ROUND
Package Style CYLINDRICAL Meter
Peak Reflow Temperature (Cel) 240
Power Supplies +-15 V
Qualification Status Not Qualified
Sub Category Multiplexer or Switches
Supply Current-Max (Isup) 2 mA
Supply Voltage-Nom (Vsup) 15 V
Surface Mount NO
Switch-off Time-Max 425 ns
Switch-on Time-Max 1000 ns
Switching BREAK-BEFORE-MAKE V
Technology CMOS
Temperature Grade OTHER
Terminal Finish TIN LEAD
Terminal Form WIRE
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 20
