KAE 3202 502 NA92 データシート

Name: KAE 3202 502 NA92
Brand: MATSUO
SKU: 210004164-0000-0000-0000

KAE 3202 502 NA92 - MATSUO の商品詳細ページです。

２営業日以内に回答いたします

KAE 3202 502 NA92 の詳細情報

型番	KAE 3202 502 NA92
メーカー	MATSUO
データシート
Additional Feature	RATED BREAKING CAPACITY AT 32 VDC: 30 A
Blow Characteristic	VERY FAST
Body Breadth	0.85 inch
Body Height	0.6 mm
Body Length or Diameter	1.6 mm
Circuit Protection Type	ELECTRIC FUSE
JESD-609 Code	e3
Joule-integral-Nom	1.6 J
Mounting Feature	SURFACE MOUNT
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Packing Method	TAPE AND REEL
Physical Dimension	1.6mm x 0.85mm x 0.6mm
Rated Breaking Capacity	30 A
Rated Current	5 A
Rated Voltage(DC)	32 V
Reference Standard	UL
Terminal Finish	Tin (Sn)
Terminal Shape	END CAP
