267E1002226KR

Name: 267E1002226KR
Brand: MATSUO
SKU: 30230301-0000-0000-0000

267E1002226KR - MATSUO の商品詳細ページです。

２営業日以内に回答いたします

267E1002226KR の詳細情報

型番	267E1002226KR
メーカー	MATSUO
Additional Feature	ESR IS MEASURED AT 100 KHZ
Capacitance	22 uF
Capacitance (uF)	22
Capacitor Type	TANTALUM CAPACITOR
Dielectric Material	TANTALUM (DRY/SOLID)
ESR (mohm)	1800
Height (mm)	1.6
J-STD-609 Code	e3
JESD-609 Code	e3
Leakage Current	.0022 mA
Leakage Current (mA)	0.0022
Length (mm)	3.2
Manufacturer Series	267E
Mounting Feature	SURFACE MOUNT
Negative Tolerance	10 %
Negative Tolerance (%)	10
Number of Terminals	2
Operating Temperature-Max	125 Cel
Operating Temperature-Max (Cel)	125
Operating Temperature-Min	-55 Cel
Operating Temperature-Min (Cel)	-55
Package Shape	RECTANGULAR PACKAGE
Package Style	SMT Meter
Packing Method	TAPE
Polarity	POLARIZED
Positive Tolerance	10 %
Positive Tolerance (%)	10
Rated DC Voltage (URdc)	10 V
Rated DC Voltage (URdc) (V)	10
Size Code	1206
Tan Delta	0.08
Terminal Finish	Tin (Sn)
Terminal Shape	J BEND
Width (mm)	1.6
