MJ-19
データシート
1
199時間55分後
以内に見積もり依頼を頂ければ、
05月08日(水) 9:00
までに見積もり回答いたします。
- 個
MJ-19 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | MJ-19 |
|---|---|
| メーカー | MARUSHIN |
| データシート |  |
| Additional Feature | CLOSED ENDS |
| Board Mounting Option | PEG |
| Body Breadth | 0.421 inch |
| Body Depth | 0.643 inch |
| Body Length | 0.62 inch |
| Body/Shell Style | JACK |
| Connector Type | CARD EDGE CONNECTOR |
| Contact Finish - Mating | AU |
| Contact Finish - Termination | GOLD FLASH |
| Contact Gender | FEMALE |
| Contact Material | COPPER ALLOY |
| Contact Pattern | RECTANGULAR |
| Contact Resistance | 11 mohm |
| Contact Style | SINGLE PRONG |
| DIN Conformance | NO |
| Dielectric Withstanding Voltage | 1400VAC V |
| Durability | 500 Cycles |
| Filter Feature | NO |
| IEC Conformance | NO |
| Insulation Resistance | 500000000 ohm |
| Insulator Color | BLACK |
| Insulator Material | GLASS FILLED POLYAMIDE |
| JESD-609 Code | e0 |
| MIL Conformance | NO |
| Manufacturer Series | MJ |
| Mating Contact Pitch | 0.1 inch |
| Mixed Contacts | NO |
| Mounting Option 1 | LOCKING |
| Mounting Style | RIGHT ANGLE |
| Mounting Type | BOARD |
| Number Of Connectors | ONE |
| Number Of PCB Rows | 2 |
| Number of Ports | 1 |
| Number of Rows Loaded | 2 |
| Operating Temperature-Max | 85 Cel |
| Operating Temperature-Min | -55 Cel |
| Option | GENERAL PURPOSE |
| PCB Contact Pattern | RECTANGULAR |
| PCB Contact Row Spacing | 5.08 mm |
| Plating Thickness | 6u inch |
| Rated Current (Signal) | 1 A |
| Reference Standard | UL |
| Reliability | COMMERCIAL |
| Shell Finish | NICKEL |
| Shell Material | BRONZE |
| Sub Category | Headers and Edge Type Connectors |
| Terminal Length | 0.19 inch |
| Terminal Pitch | 1.27 mm |
| Termination Type | PRESS FIT |
| Total Number of Contacts | 4 |
| 会社名称 | マル信無線電機株式会社 |
|---|---|
| 設立 | 1953年11月5日 |
| 資本金 | 49,500,000円 |
| 所在地 | 213-0032 神奈川県川崎市高津区久地4-26-32 |
| URL | http://www.ab.auone-net.jp/~est/index_e.html |
