MX29LV400CBTI-70G データシート

Name: MX29LV400CBTI-70G
Brand: MACRONIX
SKU: 230009951-0000-0000-0000

MX29LV400CBTI-70G - MACRONIX の商品詳細ページです。

２営業日以内に回答いたします

MX29LV400CBTI-70G の詳細情報

型番	MX29LV400CBTI-70G
メーカー	MACRONIX
データシート
Access Time-Max (ns)	70
Alternate Memory Width	8
Boot Block	BOTTOM
Command User Interface	YES
Common Flash Interface	YES
DLA Qualification	Not Qualified
Data Polling	YES
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G48
Length (mm)	18.4
Memory Density (bits)	67108864
Memory IC Type	FLASH
Memory Organization	4MX16
Memory Width	16
Moisture Sensitivity Level	3
Number of Functions	1
Number of Sectors/Size	1,2,1,7
Number of Terminals	48
Number of Words (words)	4194304
Number of Words Code	4M
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max (Cel)	85
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	TSOP1
Package Equivalence Code	TSSOP48,.8,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE Meter
Parallel/Serial	PARALLEL
Power Supplies (V)	3/3.3
Programming Voltage (V)	3
Ready/Busy	YES
Seated Height-Max (mm)	1.2
Sector Size (words)	16K,8K,32K,64K
Standby Current-Max (A)	5.0E-6
Sub Category	Flash Memories
Supply Current-Max (mA)	30
Supply Voltage-Max (V)	3.6
Supply Voltage-Min (V)	2.7
Supply Voltage-Nom (V)	3
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch (mm)	0.5
Terminal Position	DUAL
Toggle Bit	YES
Type	NOR TYPE
Width (mm)	12
