MX25U12835FZNI-10G Macronix

MX25U12835FZNI-10G

MX25U12835FZNI-10G - MACRONIX の商品詳細ページです。

1

48時間53分後 以内に見積もり依頼を頂ければ、
04月23日(火) 9:00 までに見積もり回答いたします。

  • 個
この商品のお問い合わせ

MX25U12835FZNI-10G の詳細情報

  • 仕様・詳細
  • メーカー情報
型番MX25U12835FZNI-10G
メーカーMACRONIX
Additional Feature CAN BE ORGANISED AS 128 MBIT X 1
Alternate Memory Width 2
Clock Frequency-Max (MHz) 104
DLA Qualification Not Qualified
Data Retention Time-Min 10
Endurance (Write/Erase Cycles) 100000
J-STD-609 Code e3
JESD-30 Code R-PDSO-N8
Length (mm) 6
Memory Density (bits) 134217728
Memory IC Type FLASH
Memory Organization 32MX4
Memory Width 4
Moisture Sensitivity Level 3
Number of Functions 1
Number of Terminals 8
Number of Words (words) 33554432
Number of Words Code 32M
Operating Mode SYNCHRONOUS
Operating Temperature-Max (Cel) 85
Operating Temperature-Min (Cel) -40
Package Body Material PLASTIC/EPOXY
Package Code HVSON
Package Equivalence Code SOLCC8,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Parallel/Serial SERIAL
Power Supplies (V) 1.8
Programming Voltage (V) 1.8
Seated Height-Max (mm) 0.8
Serial Bus Type SPI
Standby Current-Max (A) 2.0E-5
Sub Category Flash Memories
Supply Current-Max (mA) 20
Supply Voltage-Max (V) 2
Supply Voltage-Min (V) 1.65
Supply Voltage-Nom (V) 1.8
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form NO LEAD
Terminal Pitch (mm) 1.27
Terminal Position DUAL
Type NOR TYPE
Width (mm) 5
Write Protection HARDWARE/SOFTWARE
会社名称Macronix International Co., Ltd.
設立 December 1989
資本金NT$33.8 Billion (as of 2011/12/31
所在地No.16, Li-Hsin Road, Science Park, Hsin-chu, Taiwan, R.O.C.
URLhttp://www.macronix.com/
