MX25L51245GXDI-10G の詳細情報

  • 仕様・詳細
  • メーカー情報
型番MX25L51245GXDI-10G
メーカーMACRONIX
Additional Feature CAN BE ORGNISED AS 512 MBIT X 1
Alternate Memory Width 2
Clock Frequency-Max (fCLK) 104 MHz
JESD-30 Code R-PBGA-B24
Length 8 mm
Memory Density 536870912 bit
Memory IC Type FLASH
Memory Width 4
Number of Functions 1
Number of Terminals 24
Number of Words 134217728 words
Number of Words Code 128M
Operating Mode SYNCHRONOUS
Operating Temperature-Max 85 Cel
Operating Temperature-Min -40 Cel
Organization 128MX4
Package Body Material PLASTIC/EPOXY
Package Code TBGA
Package Shape RECTANGULAR
Package Style GRID ARRAY, THIN PROFILE Meter
Parallel/Serial SERIAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Programming Voltage 2.7 V
Seated Height-Max 1.2 mm
Supply Voltage-Max (Vsup) 3.6 V
Supply Voltage-Min (Vsup) 2.7 V
Supply Voltage-Nom (Vsup) 3 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Form BALL
Terminal Pitch 1 mm
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Width 6 mm
