MX23C1610PC-10
1
-
- 個
２営業日以内に回答いたします
MX23C1610PC-10 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | MX23C1610PC-10 |
|---|---|
| メーカー | MACRONIX |
| Access Time-Max (ns) | 100 |
| Alternate Memory Width | 8 |
| DLA Qualification | Not Qualified |
| J-STD-609 Code | e0 |
| JESD-30 Code | R-PDIP-T42 |
| Length (mm) | 51.94 |
| Memory Density (bits) | 16777216 |
| Memory IC Type | MASK ROM |
| Memory Organization | 1MX16 |
| Memory Width | 16 |
| Number of Functions | 1 |
| Number of Terminals | 42 |
| Number of Words (words) | 1048576 |
| Number of Words Code | 1M |
| Operating Mode | ASYNCHRONOUS |
| Operating Temperature-Max (Cel) | 70 |
| Operating Temperature-Min (Cel) | 0 |
| Output Characteristics | 3-STATE |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP42,.6 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Parallel/Serial | PARALLEL |
| Power Supplies (V) | 5 |
| Seated Height-Max (mm) | 4.9 |
| Standby Current-Max (A) | 5.0E-5 |
| Sub Category | MASK ROMs |
| Supply Current-Max (mA) | 60 |
| Supply Voltage-Max (V) | 5.5 |
| Supply Voltage-Min (V) | 4.5 |
| Supply Voltage-Nom (V) | 5 |
| Surface Mount | NO |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch (mm) | 2.54 |
| Terminal Position | DUAL |
| Width (mm) | 15.24 |
| 会社名称 | Macronix International Co., Ltd. |
|---|---|
| 設立 | December 1989 |
| 資本金 | NT$33.8 Billion (as of 2011/12/31 |
| 所在地 | No.16, Li-Hsin Road, Science Park, Hsin-chu, Taiwan, R.O.C. |
| URL | http://www.macronix.com/ |
