MZW-3-2

Name: MZW-3-2
Brand: MAC8
SKU: 230762105-0000-0000-0000

MZW-3-2 - MAC8 の商品詳細ページです。

２営業日以内に回答いたします

MZW-3-2 の詳細情報

型番	MZW-3-2
メーカー	MAC8
Additional Feature	DWV: 1000VDC
Body Breadth	0.157 inch
Body Depth	0.189 inch
Body Length	1 inch
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Style	RND PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	1000VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	500000000 ohm
Insulator Color	BLACK
Insulator Material	PCT-POLYESTER
MIL Conformance	NO
Manufacturer Series	MZW-3
Mating Contact Pitch	0.1 inch
Mating Contact Row Spacing	0.1 inch
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	2.54 mm
Rated Current (Signal)	2 A
Reference Standard	UL
Terminal Length	0.138 inch
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	16
UL Flammability Code	94V-0
