LY625128SL-55LLI データシート

Name: LY625128SL-55LLI
Brand: LYONTEK
SKU: 220078592-0000-0000-0000

LY625128SL-55LLI - LYONTEK の商品詳細ページです。

２営業日以内に回答いたします

LY625128SL-55LLI の詳細情報

型番	LY625128SL-55LLI
メーカー	LYONTEK
データシート
Access Time-Max (ns)	55
Additional Feature	LG_MAX
DLA Qualification	Not Qualified
I/O Type	COMMON
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G32
Length (mm)	20.75
Memory Density (bits)	4194304
Memory IC Type	STANDARD SRAM
Memory Organization	512KX8
Memory Width	8
Moisture Sensitivity Level	3
Number of Functions	1
Number of Ports	1
Number of Terminals	32
Number of Words (words)	524288
Number of Words Code	512K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max (Cel)	85
Operating Temperature-Min (Cel)	-40
Output Characteristics	3-STATE
Output Enable	YES
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP32,.56
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Cel)	245
Power Supplies (V)	5
Seated Height-Max (mm)	3.048
Standby Current-Max (A)	3.0E-5
Standby Voltage-Min (V)	1.5
Sub Category	SRAMs
Supply Current-Max (mA)	60
Supply Voltage-Max (V)	5.5
Supply Voltage-Min (V)	4.5
Supply Voltage-Nom (V)	5
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch (mm)	1.27
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width (mm)	11.303

会社名称	Lyontek Inc.
設立	2003
所在地	5F,No. 2,lndustry E. Rd. IX, Science-Based Industrial Park, Hsinchu 300, Taiwan, R.O.C.
URL	http://www.lyontek.com.tw/
