SP4021-01FTG

Name: SP4021-01FTG
Brand: LITTLEFUSE
SKU: 290448163-0000-0000-0000

SP4021-01FTG - LITTLEFUSE の商品詳細ページです。

２営業日以内に回答いたします

SP4021-01FTG の詳細情報

型番	SP4021-01FTG
メーカー	LITTLEFUSE
Additional Feature	LOW CAPACITANCE
Breakdown Voltage-Min	6.3 V
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 Code	R-PDSO-G2
JESD-609 Code	e3
Non-rep Peak Rev Power Dis-Max	600 W
Number of Elements	1
Number of Terminals	2
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity	BIDIRECTIONAL
Reference Standard	AEC-Q101; IEC-61000-4-2, 4-4, 4-5
Rep Pk Reverse Voltage-Max	5 V
Surface Mount	YES
Technology	AVALANCHE
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
