R451010.MR
1
-
- 個
２営業日以内に回答いたします
R451010.MR の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | R451010.MR |
|---|---|
| メーカー | LITTLEFUSE |
| Additional Feature | PRE ARCHING TIME: OPEN WITHIN 5 SEC AT 200% RATED CURRENT; RATED BREAKING CAPACITY AT 32 VDC: 50 A |
| Blow Characteristic | VERY FAST |
| Body Breadth | 2.69 inch |
| Body Height | 2.69 mm |
| Body Length or Diameter | 6.1 mm |
| Circuit Protection Type | ELECTRIC FUSE |
| Fuse Size | NANO |
| JESD-609 Code | e0 |
| Joule-integral-Nom | 26.46 J |
| Manufacturer Series | 451 |
| Mounting Feature | SURFACE MOUNT |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -55 Cel |
| Packing Method | TAPE AND REEL |
| Physical Dimension | 6.1mm x 2.69mm x 2.69mm |
| Rated Breaking Capacity | 35 A |
| Rated Current | 10 A |
| Rated Voltage(AC) | 125 V |
| Rated Voltage(DC) | 125 V |
| Reference Standard | CSA; PSE; UL |
| Terminal Finish | GOLD |
| Terminal Shape | WRAPAROUND |
| Trip Time or Delay | 5 Seconds |
| 会社名称 | Littelfuse, Inc. |
|---|---|
| 設立 | 1927 |
| 所在地 | 8755 West Higgins Road Suite 500, Chicago, IL, 60631 USA, |
| URL | http://www.littelfuse.com/ |
