5KP5.0A の詳細情報

型番	5KP5.0A
メーカー	LITTLEFUSE
データシート
Additional Feature	CAPACITANCE IS CAPTURED FROM THE GRAPH
Breakdown Voltage-Max	7 V
Breakdown Voltage-Max (V)	7
Breakdown Voltage-Min	6.4 V
Breakdown Voltage-Min (V)	6.4
Breakdown Voltage-Nom	6.7 V
Breakdown Voltage-Nom (V)	6.7
Case Connection	ISOLATED
Clamping Voltage-Max	9.2 V
Clamping Voltage-Max (V)	9.2
Configuration	SINGLE
DLA Qualification	Not Qualified
Diode Capacitance-Min	90000 pF
Diode Element Material	SILICON
Diode Type	TRANS VOLTAGE SUPPRESSOR DIODE
Forward Voltage-Max (V)	3.5
Forward Voltage-Max (VF)	3.5 V
J-STD-609 Code	e0
JEDEC-95 Code	DO-204AR
JESD-30 Code	O-LALF-W2
JESD-609 Code	e0
Moisture Sensitivity Level	1
Non-rep Peak Rev Power Dis-Max	500 W
Non-rep Peak Rev Power Dis-Max (W)	5000
Number of Elements	1
Number of Terminals	2
Operating Temperature-Max	150 Cel
Operating Temperature-Max (Cel)	175
Operating Temperature-Min	-65 Cel
Operating Temperature-Min (Cel)	-55
Package Body Material	GLASS
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	240
Polarity	UNIDIRECTIONAL
Power Dissipation-Max	1.56 W
Power Dissipation-Max (W)	8
Qualification Status	Not Qualified
Reference Standard	IEC-61000-4-2, 4-4, 4-5
Rep Pk Reverse Voltage-Max	5 V
Rep Pk Reverse Voltage-Max (V)	5
Reverse Current-Max	2000 uA
Reverse Test Voltage	5 V
Sub Category	Transient Suppressors
Surface Mount	NO
Technology	AVALANCHE
Terminal Finish	MATTE TIN
Terminal Form	NO LEAD
Terminal Position	AXIAL
Time@Peak Reflow Temperature-Max (s)	10
