251.250
1
-
- 個
２営業日以内に回答いたします
251.250 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 251.250 |
|---|---|
| メーカー | LITTLEFUSE |
| Additional Feature | RATED BREAKING CAPACITY AT 125 VDC: 300 A, PRE ARCING TIME: OPEN WITHIN 1 SEC AT 200% RATED CURRENT |
| Blow Characteristic | FAST |
| Body Height | 7.11 mm |
| Body Length or Diameter | 2.413 mm |
| Circuit Protection Type | ELECTRIC FUSE |
| Fuse Size | PICO |
| JESD-609 Code | e0 |
| Joule-integral-Nom | 0.0116 J |
| Mounting Feature | THROUGH HOLE |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -55 Cel |
| Physical Dimension | 2.8mm x 7.11mm |
| Rated Breaking Capacity | 50 A |
| Rated Current | 0.25 A |
| Rated Voltage | 125 V |
| Rated Voltage(AC) | 125 V |
| Rated Voltage(DC) | 125 V |
| Reference Standard | CSA; QPL; TUV; UL |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Shape | PIN WIRE |
| Trip Time or Delay | 1 Seconds |
| 会社名称 | Littelfuse, Inc. |
|---|---|
| 設立 | 1927 |
| 所在地 | 8755 West Higgins Road Suite 500, Chicago, IL, 60631 USA, |
| URL | http://www.littelfuse.com/ |
