0251001.MXL データシート

Name: 0251001.MXL
Brand: LITTLEFUSE
SKU: 10000100-0000-0000-0000

0251001.MXL - LITTLEFUSE の商品詳細ページです。

２営業日以内に回答いたします

0251001.MXL の詳細情報

型番	0251001.MXL
メーカー	LITTLEFUSE
データシート
Additional Feature	PRE-ARCING TIME: OPEN WITHIN 4 MS AT 1000% RATED CURRENT
Blow Characteristic	VERY FAST
Body Height	7.11 mm
Body Length or Diameter	2.8 mm
Circuit Protection Type	ELECTRIC FUSE
Fuse Class	Supplemental
Fuse Size	PICO
JESD-609 Code	e3
Joule-integral-Nom	0.256 J
Mounting Feature	THROUGH HOLE
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Packing Method	BULK
Physical Dimension	2.8mm x 7.11mm
Pre-arcing Rating	0.256 A2/s
Rated Breaking Capacity	50 A
Rated Current	1 A
Rated Voltage	125 V
Rated Voltage(AC)	125 V
Rated Voltage(DC)	125 V
Reference Standard	CCC; CSA; CUL; PSE; TUV; UL
Terminal Finish	MATTE TIN
Terminal Shape	PIN WIRE
Trip Time or Delay	0.004 Seconds
