LTST-C190GKT データシート

Name: LTST-C190GKT
Brand: LITE-ON
SKU: 220007946-0000-0000-0000

LTST-C190GKT - LITE-ON の商品詳細ページです。

２営業日以内に回答いたします

LTST-C190GKT の詳細情報

型番	LTST-C190GKT
メーカー	LITE-ON
データシート
Additional Feature	IC COMPATIBLE
Color	GREEN
Configuration	SINGLE
Forward Current-Max	0.03 A
Forward Current-Max (A)	0.03
Forward Voltage-Max	2.6 V
JESD-609 Code	e3
Lens Type	WATER CLEAR
Luminous Intensity-Min	0.0018 cd
Luminous Intensity-Nom	9.9 mcd
Luminous Intensity-Nom (mcd)	2.3
Mounting Feature	SURFACE MOUNT
Number of Functions	1
Number of LEDs in Array	1
Number of Terminals	2
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-55 Cel
Operating Temperature-Min (Cel)	-55
Optoelectronic Device Type	SINGLE COLOR LED
Overall Height	0.8 mm
Overall Height (mm)	0.8
Packing Method	TR, 7 INCH
Peak Wavelength	565 nm
Peak Wavelength (nm)	565
Reverse Voltage-Max	5 V
Shape	RECTANGULAR
Size	1.1 mm
Size (mm)	1.06
Terminal Finish	Pure Tin (Sn)
Terminal Pitch	1.5 mm
Terminal Pitch (mm)	1.5
Viewing Angle	130 deg
Viewing Angle (deg)	130
