LTM4620AEV#PBF

Name: LTM4620AEV#PBF
Brand: LINEAR TECH
SKU: 220206711-0000-0000-0000

LTM4620AEV#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTM4620AEV#PBF の詳細情報

型番	LTM4620AEV#PBF
メーカー	LINEAR TECH
Additional Feature	OPERATES IN ADJUSTABLE MODE FROM 0.6V TO 5.3V; ACTS AS SINGLE OR DUAL OUTPUT REGULATOR
Analog IC - Other Type	SWITCHING CONTROLLER
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	16 V
Input Voltage-Max (V)	16
Input Voltage-Min	4.5 V
Input Voltage-Min (V)	4.5
Input Voltage-Nom	12 V
Input Voltage-Nom (V)	12
JESD-30 Code	S-PBGA-N144
Length	15 mm
Length (mm)	15
Moisture Sensitivity Level	3
Number of Functions	1
Number of Terminals	144
Operating Temperature-Max	125 Cel
Operating Temperature-Max (Cel)	125
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Output Current-Max	13 A
Package Body Material	PLASTIC/EPOXY
Package Code	LGA
Package Equivalence Code	LGA144,12X12,50
Package Shape	SQUARE
Package Style	GRID ARRAY Meter
Peak Reflow Temperature (Cel)	245
Qualification Status	Not Qualified
Seated Height-Max	4.51 mm
Seated Height-Max (mm)	4.51
Sub Category	Switching Regulator or Controllers
Surface Mount	YES
Switcher Configuration	PHASE-SHIFT
Switching Frequency-Max	780 kHz
Switching Frequency-Max (kHz)	780
Temperature Grade	AUTOMOTIVE
Terminal Form	NO LEAD
Terminal Pitch	1.27 mm
Terminal Pitch (mm)	1.27
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	30
Width	15 mm
Width (mm)	15
