LTC6655BHLS8-2.5#PBF

Name: LTC6655BHLS8-2.5#PBF
Brand: LINEAR TECH
SKU: 220223901-0000-0000-0000

LTC6655BHLS8-2.5#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTC6655BHLS8-2.5#PBF の詳細情報

型番	LTC6655BHLS8-2.5#PBF
メーカー	LINEAR TECH
Additional Feature	SEATED HT-CALCULATED
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 Code	S-CQCC-N8
Length	5 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Voltage-Max	2.500625 V
Output Voltage-Min	2.499375 V
Output Voltage-Nom	2.5 V
Package Body Material	CERAMIC, METAL-SEALED COFIRED
Package Code	HQCCN
Package Equivalence Code	LCC8,.2SQ
Package Shape	SQUARE
Package Style	CHIP CARRIER, HEAT SINK/SLUG Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Seated Height-Max	1.55 mm
Sub Category	Voltage References
Supply Current-Max (Isup)	7.5 mA
Supply Voltage-Max (Vsup)	13.2 V
Supply Voltage-Min (Vsup)	3 V
Surface Mount	YES
Technology	CMOS
Temp Coef of Voltage-Max	2 ppm/Cel
Temperature Grade	AUTOMOTIVE
Terminal Form	NO LEAD
Terminal Pitch	1.27 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	0.025 %
Width	5 mm
