LTC6241HVCS8#PBF

Name: LTC6241HVCS8#PBF
Brand: LINEAR TECH
SKU: 220195461-0000-0000-0000

LTC6241HVCS8#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTC6241HVCS8#PBF の詳細情報

型番	LTC6241HVCS8#PBF
メーカー	LINEAR TECH
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)	7.5E-5 uA
Average Bias Current-Max (IIB) (uA)	7.5E-5
Common-mode Reject Ratio-Nom	105 dB
Common-mode Reject Ratio-Nom (dB)	105
DLA Qualification	Not Qualified
Frequency Compensation	YES
Input Offset Voltage-Max	275 uV
Input Offset Voltage-Max (uV)	275
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e3
Length	4.9 mm
Length (mm)	4.9
Low-Bias	YES
Low-Offset	YES
Micropower	NO
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-6 V
Neg Supply Voltage Limit-Max (V)	-6
Neg Supply Voltage-Nom (Vsup)	-5 V
Negative Supply Voltage-Nom (V)	-5
Number of Functions	2
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power	NO
Power Supplies	3/5/+-5 V
Programmable Power	NO
Qualification Status	Not Qualified
Seated Height-Max	1.752 mm
Seated Height-Max (mm)	1.752
Slew Rate-Nom	10 V/us
Sub Category	Operational Amplifier
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
