LTC2616IDD-1#PBF

Name: LTC2616IDD-1#PBF
Brand: LINEAR TECH
SKU: 220223964-0000-0000-0000

LTC2616IDD-1#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTC2616IDD-1#PBF の詳細情報

型番	LTC2616IDD-1#PBF
メーカー	LINEAR TECH
Analog Output Voltage-Max	5.5 V
Analog Output Voltage-Max (V)	5.5
Analog Output Voltage-Min	0 V
Analog Output Voltage-Min (V)	0
Converter Type	D/A CONVERTER
DLA Qualification	Not Qualified
Input Bit Code	BINARY
Input Format	SERIAL
J-STD-609 Code	e3
JESD-30 Code	S-PDSO-N10
JESD-609 Code	e3
Length	3 mm
Length (mm)	3
Linearity Error-Max (EL)	0.0977 %
Linearity Error-Max (EL) (%)	0.0977
Moisture Sensitivity Level	1
Number of Bits	14
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	HVSON
Package Equivalence Code	SOLCC10,.11,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3/5 V
Qualification Status	Not Qualified
Seated Height-Max	0.8 mm
Seated Height-Max (mm)	0.8
Settling Time-Nom (tstl)	9 us
Settling Time-Nom (tstl) (us)	9
Sub Category	Other Converters
Supply Current-Max	0.5 mA
Supply Voltage-Nom	3 V
Supply Voltage-Nom (V)	3
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Pitch (mm)	0.5
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm
Width (mm)	3
