LTC2057IMS8#PBF

Name: LTC2057IMS8#PBF
Brand: LINEAR TECH
SKU: 220219069-0000-0000-0000

LTC2057IMS8#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTC2057IMS8#PBF の詳細情報

型番	LTC2057IMS8#PBF
メーカー	LINEAR TECH
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	CHOPPER-STAB
Average Bias Current-Max (IIB)	0.00036 uA
Average Bias Current-Max (IIB) (uA)	0.00036
Bias Current-Max (IIB) @25C	0.0002 uA
Common-mode Reject Ratio-Nom	150 dB
Common-mode Reject Ratio-Nom (dB)	150
Frequency Compensation	YES
Input Offset Voltage-Max	4.5 uV
Input Offset Voltage-Max (uV)	4.5
J-STD-609 Code	e3
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e3
Length	3 mm
Length (mm)	3
Low-Bias	YES
Low-Offset	YES
Micropower	NO
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-20 V
Neg Supply Voltage Limit-Max (V)	-20
Neg Supply Voltage-Nom (Vsup)	-15 V
Negative Supply Voltage-Nom (V)	-15
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power	NO
Power Supplies	+-2.5/+-15 V
Programmable Power	NO
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Seated Height-Max (mm)	1.1
Slew Rate-Nom	0.45 V/us
Sub Category	Operational Amplifier
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
