LTC2050CS5#PBF Lineartech

LTC2050CS5#PBF - LINEAR TECH の商品詳細ページです。

1
LTC2050CS5#PBF
  • LTC2050CS5#PBF
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

LTC2050CS5#PBF の詳細情報

  • 仕様・詳細
  • メーカー情報
型番LTC2050CS5#PBF
メーカーLINEAR TECH
Amplifier Type OPERATIONAL AMPLIFIER
Architecture CHOPPER-STAB
Average Bias Current-Max (IIB) 0.0003 uA
Average Bias Current-Max (IIB) (uA) 0.0003
Bias Current-Max (IIB) @25C 0.00015 uA
Common-mode Reject Ratio-Nom 130 dB
Common-mode Reject Ratio-Nom (dB) 130
DLA Qualification Not Qualified
Frequency Compensation YES
Input Offset Voltage-Max 3 uV
Input Offset Voltage-Max (uV) 3
J-STD-609 Code e3
JESD-30 Code R-PDSO-G5
JESD-609 Code e3
Length 2.9 mm
Length (mm) 2.9
Low-Bias YES
Low-Offset YES
Moisture Sensitivity Level 1
Number of Functions 1
Number of Terminals 5
Operating Temperature-Max 70 Cel
Operating Temperature-Max (Cel) 70
Operating Temperature-Min 0 Cel
Operating Temperature-Min (Cel) 0
Package Body Material PLASTIC/EPOXY
Package Code VSSOP
Package Equivalence Code TSOP5/6,.11,37
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel) 260
Power Supplies 3/5 V
Qualification Status Not Qualified
Seated Height-Max 1 mm
Seated Height-Max (mm) 1
Slew Rate-Nom 2 V/us
Slew Rate-Nom (V/us) 2
Sub Category Operational Amplifier
Supply Current-Max 1.2 mA
Supply Voltage Limit-Max 7 V
Supply Voltage Limit-Max (V) 7
Supply Voltage-Nom (V) 3
Supply Voltage-Nom (Vsup) 3 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
会社名称Linear Technology Corporate
所在地1630 McCarthy Blvd. Milpitas, CA 95035-7417 USA
URLhttp://www.linear.com/
