LTC1871IMS#PBF

Name: LTC1871IMS#PBF
Brand: LINEAR TECH
SKU: 220192802-0000-0000-0000

LTC1871IMS#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTC1871IMS#PBF の詳細情報

型番	LTC1871IMS#PBF
メーカー	LINEAR TECH
Analog IC - Other Type	SWITCHING CONTROLLER
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
DLA Qualification	Not Qualified
Input Voltage-Max	36 V
Input Voltage-Max (V)	36
Input Voltage-Min	2.5 V
Input Voltage-Min (V)	2.5
Input Voltage-Nom	5 V
Input Voltage-Nom (V)	5
J-STD-609 Code	e3
JESD-30 Code	S-PDSO-G10
JESD-609 Code	e3
Length	3 mm
Length (mm)	3
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	10
Operating Temperature-Max	125 Cel
Operating Temperature-Max (Cel)	125
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Output Current-Max	0.05 A
Output Current-Max (A)	0.05
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP10,.19,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Seated Height-Max (mm)	1.1
Sub Category	Switching Regulator or Controllers
Surface Mount	YES
Switcher Configuration	SINGLE
Switching Frequency-Max	1000 kHz
Switching Frequency-Max (kHz)	1000
Technology	CMOS
Temperature Grade	AUTOMOTIVE
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Pitch (mm)	0.5
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm
Width (mm)	3
