LTC1569CS8-7
1
-
- 個
２営業日以内に回答いたします
LTC1569CS8-7 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | LTC1569CS8-7 |
|---|---|
| メーカー | LINEAR TECH |
| Active Filter Type | CONTINUOUS TIME FILTER |
| Additional Feature | UP TO 300KHZ CUTOFF ON A SINGLE 5V SUPPLY, CAN ALSO OPERATE FROM A +/-5V SUPPLY |
| Center or Cutoff Freq Rng-Max | 150 kHz |
| Center or Cutoff Freq Rng-Min | 0 kHz |
| JESD-30 Code | R-PDSO-G8 |
| JESD-609 Code | e0 |
| Length | 4.9 mm |
| Moisture Sensitivity Level | 1 |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | 0 Cel |
| Order | 10TH |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | SOP |
| Package Equivalence Code | SOP8,.25 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Poles and Zeros | 10 AND 0 |
| Power Supplies | 3 V |
| Qualification Status | Not Qualified |
| Response | LOWPASS |
| Seated Height-Max | 1.75 mm |
| Sub Category | Active Filters |
| Supply Current-Max (Isup) | 37 mA |
| Supply Voltage-Max (Vsup) | 4.6 V |
| Supply Voltage-Min (Vsup) | 2.7 V |
| Supply Voltage-Nom (Vsup) | 3 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Transfer Characteristics | PIN OR RESISTOR PROGRAMMABLE |
| Width | 3.9 mm |
| 会社名称 | Linear Technology Corporate |
|---|---|
| 所在地 | 1630 McCarthy Blvd. Milpitas, CA 95035-7417 USA |
| URL | http://www.linear.com/ |
