LTC1043CN データシート

Name: LTC1043CN
Brand: LINEAR TECH
SKU: 220001945-0000-0000-0000

LTC1043CN - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LTC1043CN の詳細情報

型番	LTC1043CN
メーカー	LINEAR TECH
データシート
Additional Feature	IT CAN ALSO BE OPERATED FROM A +/-5V DUAL SUPPLY
Analog IC - Other Type	ANALOG CIRCUIT
DLA Qualification	Not Qualified
J-STD-609 Code	e3
JESD-30 Code	R-PDIP-T18
JESD-609 Code	e0
Moisture Sensitivity Level	1
Number of Functions	2
Number of Terminals	18
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP18,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	3.937 mm
Seated Height-Max (mm)	3.937
Sub Category	Other Analog ICs
Supply Current-Max (Isup)	1 mA
Supply Voltage-Max (V)	18
Supply Voltage-Max (Vsup)	18 V
Supply Voltage-Min (V)	3
Supply Voltage-Min (Vsup)	3 V
Supply Voltage-Nom (V)	10
Supply Voltage-Nom (Vsup)	10 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Pitch (mm)	2.54
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	7.62 mm
Width (mm)	7.62
