- LT6600CS8-10#PBF
LT6600CS8-10#PBF
1
No Image
-
- 個
２営業日以内に回答いたします
LT6600CS8-10#PBF の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | LT6600CS8-10#PBF |
|---|---|
| メーカー | LINEAR TECH |
| Additional Feature | CAN ALSO OPERATE FROM A SINGLE 3V OR 5V SUPPLY |
| Analog IC - Other Type | ANALOG CIRCUIT |
| DLA Qualification | Not Qualified |
| J-STD-609 Code | e3 |
| JESD-30 Code | R-PDSO-G8 |
| JESD-609 Code | e3 |
| Length | 4.9 mm |
| Length (mm) | 4.9 |
| Moisture Sensitivity Level | 1 |
| Neg Supply Voltage-Nom (Vsup) | -5 V |
| Negative Supply Voltage-Nom (V) | -5 |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Max (Cel) | 70 |
| Operating Temperature-Min | 0 Cel |
| Operating Temperature-Min (Cel) | 0 |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | SOP |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Qualification Status | Not Qualified |
| Seated Height-Max | 1.752 mm |
| Seated Height-Max (mm) | 1.752 |
| Supply Voltage-Nom (V) | 5 |
| Supply Voltage-Nom (Vsup) | 5 V |
| Surface Mount | YES |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Pitch (mm) | 1.27 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width | 3.9 mm |
| Width (mm) | 3.9 |
| 会社名称 | Linear Technology Corporate |
|---|---|
| 所在地 | 1630 McCarthy Blvd. Milpitas, CA 95035-7417 USA |
| URL | http://www.linear.com/ |
