LT3060ETS8-1.2#TRMPBF の詳細情報

  • 仕様・詳細
  • メーカー情報
型番LT3060ETS8-1.2#TRMPBF
メーカーLINEAR TECH
Adjustability FIXED
DLA Qualification Not Qualified
Dropout Voltage1-Max 0.51 V
Dropout Voltage1-Max (V) 0.51
Input Voltage Absolute-Max 50 V
Input Voltage-Max 45 V
Input Voltage-Max (V) 45
Input Voltage-Min 2.1 V
Input Voltage-Min (V) 2.1
J-STD-609 Code e3
JESD-30 Code R-PDSO-G8
JESD-609 Code e3
Length 2.9 mm
Length (mm) 2.9
Line Regulation-Max 0.0035 %
Load Regulation-Max 0.01 %
Number of Functions 1
Number of Outputs 1
Number of Terminals 8
Operating Temperature TJ-Max (Cel) 125
Operating Temperature TJ-Min (Cel) -40
Operating Temperature, TJ-Max 125 Cel
Operating Temperature, TJ-Min -40 Cel
Output Current1-Max 0.1 A
Output Current1-Max (A) 0.1
Output Voltage1-Max 1.224 V
Output Voltage1-Max (V) 1.224
Output Voltage1-Min 1.176 V
Output Voltage1-Min (V) 1.176
Output Voltage1-Nom 1.2 V
Output Voltage1-Nom (V) 1.2
Package Body Material PLASTIC/EPOXY
Package Code VSSOP
Package Equivalence Code TSSOP8,.1
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter
Packing Method TR
Qualification Status Not Qualified
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max 1 mm
Seated Height-Max (mm) 1
Sub Category Other Regulators
Surface Mount YES
Technology BIPOLAR
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Pitch (mm) 0.65
Terminal Position DUAL
Voltage Tolerance-Max 2 %
