LT3021ES8

Name: LT3021ES8
Brand: LINEAR TECH
SKU: 220026795-0000-0000-0000

LT3021ES8 - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LT3021ES8 の詳細情報

型番	LT3021ES8
メーカー	LINEAR TECH
Adjustability	ADJUSTABLE
DLA Qualification	Not Qualified
Dropout Voltage1-Max	0.285 V
Dropout Voltage1-Max (V)	0.285
Dropout Voltage1-Nom	0.155 V
Input Voltage Absolute-Max	10 V
Input Voltage-Max	10 V
Input Voltage-Min	1.5 V
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e0
Length	4.9025 mm
Length (mm)	4.9025
Line Regulation-Max	0.0105 %
Load Regulation-Max	0.006 %
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature TJ-Max (Cel)	125
Operating Temperature TJ-Min (Cel)	-40
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	0.5 A
Output Current1-Max (A)	0.5
Output Voltage1-Max	1.236 V
Output Voltage1-Max (V)	1.236
Output Voltage1-Min	0.2 V
Output Voltage1-Min (V)	0.2
Output Voltage1-Nom	1.2 V
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	235
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	1.752 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Voltage Tolerance-Max	3.5 %
Width	3.899 mm
