LT1469ACDF#PBF

Name: LT1469ACDF#PBF
Brand: LINEAR TECH
SKU: 220201172-0000-0000-0000

LT1469ACDF#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LT1469ACDF#PBF の詳細情報

型番	LT1469ACDF#PBF
メーカー	LINEAR TECH
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Bias Current-Max (IIB) @25C	0.04 uA
Common-mode Reject Ratio-Nom	112 dB
Common-mode Reject Ratio-Nom (dB)	112
DLA Qualification	Not Qualified
Frequency Compensation	YES
Input Offset Voltage-Max	275 uV
Input Offset Voltage-Max (uV)	275
J-STD-609 Code	e3
JESD-30 Code	S-PDSO-N12
JESD-609 Code	e3
Length	4 mm
Length (mm)	4
Low-Bias	NO
Low-Offset	YES
Micropower	NO
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage Limit-Max (V)	-18
Neg Supply Voltage-Nom (Vsup)	-5 V
Negative Supply Voltage-Nom (V)	-5
Number of Functions	2
Number of Terminals	12
Operating Temperature-Max	70 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Package Body Material	PLASTIC/EPOXY
Package Code	HVSON
Package Equivalence Code	SOLCC12,.16,20
Package Shape	SQUARE
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Power	NO
Power Supplies	+-5/+-15 V
Programmable Power	NO
Qualification Status	Not Qualified
Seated Height-Max	0.8 mm
Seated Height-Max (mm)	0.8
Slew Rate-Min	9 V/us
Slew Rate-Nom	17 V/us
Slew Rate-Nom (V/us)	17
Sub Category	Operational Amplifier
Surface Mount	YES
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	NO LEAD
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
