LT1460DCS8-5#PBF

Name: LT1460DCS8-5#PBF
Brand: LINEAR TECH
SKU: 220223748-0000-0000-0000

LT1460DCS8-5#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LT1460DCS8-5#PBF の詳細情報

型番	LT1460DCS8-5#PBF
メーカー	LINEAR TECH
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
DLA Qualification	Not Qualified
J-STD-609 Code	e3
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e3
Length	4.9025 mm
Length (mm)	4.9025
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Output Voltage-Max	5.005 V
Output Voltage-Max (V)	5.005
Output Voltage-Min	4.995 V
Output Voltage-Min (V)	4.995
Output Voltage-Nom	5 V
Output Voltage-Nom (V)	5
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.752 mm
Seated Height-Max (mm)	1.752
Sub Category	Voltage References
Supply Voltage-Max (V)	20
Supply Voltage-Max (Vsup)	20 V
Supply Voltage-Min (V)	5.9
Supply Voltage-Min (Vsup)	5.9 V
Supply Voltage-Nom (V)	7.5
Supply Voltage-Nom (Vsup)	7.5 V
Surface Mount	YES
Technology	BIPOLAR
Temp Coef of Voltage-Max	20 ppm/Cel
Temp Coef of Voltage-Max (ppm/Cel)	20
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Pitch (mm)	1.27
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	0.1 %
