LT1374CR の詳細情報

型番	LT1374CR
メーカー	LINEAR TECH
データシート
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
DLA Qualification	Not Qualified
Input Voltage-Max	25 V
Input Voltage-Max (V)	25
Input Voltage-Min	5 V
Input Voltage-Min (V)	5
Input Voltage-Nom	15 V
Input Voltage-Nom (V)	15
J-STD-609 Code	e3
JESD-30 Code	R-PSSO-G7
JESD-609 Code	e0
Length	10.2235 mm
Length (mm)	10.2235
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	7
Operating Temperature-Max	125 Cel
Operating Temperature-Max (Cel)	125
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Output Current-Max	8.5 A
Output Current-Max (A)	8.5
Package Body Material	PLASTIC/EPOXY
Package Code	TO-263
Package Equivalence Code	SMSIP7H,.55,50TB
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	235
Qualification Status	Not Qualified
Seated Height-Max	4.572 mm
Seated Height-Max (mm)	4.572
Sub Category	Switching Regulator or Controllers
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	560 kHz
Switching Frequency-Max (kHz)	560
Technology	BIPOLAR
Temperature Grade	OTHER
Terminal Finish	MATTE TIN OVER NICKEL
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Pitch (mm)	1.27
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	20
Width	8.89 mm
Width (mm)	8.89
