LT1019CN8-4.5#PBF

Name: LT1019CN8-4.5#PBF
Brand: LINEAR TECH
SKU: 220201049-0000-0000-0000

LT1019CN8-4.5#PBF - LINEAR TECH の商品詳細ページです。

２営業日以内に回答いたします

LT1019CN8-4.5#PBF の詳細情報

型番	LT1019CN8-4.5#PBF
メーカー	LINEAR TECH
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
DLA Qualification	Not Qualified
J-STD-609 Code	e3
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e3
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	0 Cel
Operating Temperature-Min (Cel)	0
Output Voltage-Max	4.509 V
Output Voltage-Max (V)	4.509
Output Voltage-Min	4.491 V
Output Voltage-Min (V)	4.491
Output Voltage-Nom	4.5 V
Output Voltage-Nom (V)	4.5
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Qualification Status	Not Qualified
Seated Height-Max	3.937 mm
Seated Height-Max (mm)	3.937
Sub Category	Voltage References
Supply Current-Max (Isup)	1.5 mA
Supply Current-Max (mA)	1.5
Supply Voltage-Max (V)	40
Supply Voltage-Max (Vsup)	40 V
Supply Voltage-Min (V)	6
Supply Voltage-Min (Vsup)	6 V
Supply Voltage-Nom (V)	15
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	NO
Technology	BIPOLAR
Temp Coef of Voltage-Max	20 ppm/Cel
Temp Coef of Voltage-Max (ppm/Cel)	20
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Pitch (mm)	2.54
Terminal Position	DUAL
Trim/Adjustable Output	YES V
Voltage Tolerance-Max	0.2 %
Width	7.62 mm
Width (mm)	7.62
