24 5077 030 112 861+

Name: 24 5077 030 112 861+
Brand: KYOCERA
SKU: 30259659-0000-0000-0000

24 5077 030 112 861+ - KYOCERA の商品詳細ページです。

２営業日以内に回答いたします

24 5077 030 112 861+ の詳細情報

型番	24 5077 030 112 861+
メーカー	KYOCERA
Board Mounting Option	PEG
Body Breadth	0.276 inch
Body Depth	0.311 inch
Body Length	0.866 inch
Body/Shell Style	RECEPTACLE
Connector Type	BOARD STACKING CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Style	BELLOWED TYPE
Dielectric Withstanding Voltage	707VAC V
Filter Feature	NO
Insulator Material	PLASTIC
Mating Contact Pitch	0.039 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	5.7 mm
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	0.5 A
Terminal Pitch	1 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	30
