208261024900878

Name: 208261024900878
Brand: KYOCERA
SKU: 30263267-0000-0000-0000

208261024900878 - KYOCERA の商品詳細ページです。

２営業日以内に回答いたします

208261024900878 の詳細情報

型番	208261024900878
メーカー	KYOCERA
Body Breadth	0.098 inch
Body Depth	0.236 inch
Body Length	0.197 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	AU ON NI
Contact Finish - Termination	NOT APPLICABLE
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	12 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	750VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Color	GREEN
Insulator Material	POLYBUTYLENE TEREPHTHALATE
MIL Conformance	NO
Manufacturer Series	8261
Mating Contact Pitch	0.1 inch
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	CABLE
Number Of Connectors	ONE
Number of Rows Loaded	1
Option	GENERAL PURPOSE
Plating Thickness	15u inch
Rated Current (Signal)	3 A
Reliability	COMMERCIAL
Sub Category	Other Interconnects
Termination Type	IDC
Total Number of Contacts	2
