10-5061-030-000-856+

Name: 10-5061-030-000-856+
Brand: KYOCERA
SKU: 20505425-0000-0000-0000

10-5061-030-000-856+ - KYOCERA の商品詳細ページです。

２営業日以内に回答いたします

10-5061-030-000-856+ の詳細情報

型番	10-5061-030-000-856+
メーカー	KYOCERA
Body Breadth	0.276 inch
Body Depth	0.382 inch
Body Length	0.976 inch
Body/Shell Style	PLUG
Connector Type	BOARD STACKING CONNECTOR
Contact Gender	MALE
Contact Pattern	RECTANGULAR
Contact Style	CENTRONIC
Dielectric Withstanding Voltage	900VAC V
Filter Feature	NO
Insulator Material	PLASTIC
Mating Contact Pitch	0.05 inch
Mating Information	MULTIPLE MATING PARTS ARE AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	4
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	STAGGERED
PCB Contact Row Spacing	1.905 mm
Rated Current (Signal)	0.5 A
Terminal Length	0.118 inch
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	30
