00 8263 031 100 000+ の詳細情報

  • 仕様・詳細
  • メーカー情報
型番00 8263 031 100 000+
メーカーKYOCERA
Body Breadth 0.146 inch
Body Depth 0.382 inch
Body Length 0.291 inch
Body/Shell Style PLUG
Connector Type BOARD CONNECTOR
Contact Gender MALE
Contact Pattern RECTANGULAR
Contact Resistance 20 mohm
Contact Style SQ PIN-SKT
Dielectric Withstanding Voltage 1000VAC V
Filter Feature NO
Insulation Resistance 1000000000 ohm
Insulator Color WHITE
Insulator Material POLYAMIDE66
Mating Contact Pitch 0.098 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Style RIGHT ANGLE
Mounting Type BOARD
Number Of Connectors ONE
Number Of PCB Rows 1
Number of Rows Loaded 1
Operating Temperature-Max 85 Cel
Operating Temperature-Min -40 Cel
Option GENERAL PURPOSE
PCB Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Rated Current (Signal) 3 A
Reference Standard UL
Terminal Length 0.134 inch
Terminal Pitch 2.5 mm
Termination Type SOLDER
Total Number of Contacts 3
UL Flammability Code 94V-0
